A2-23C
Home / Product / Accessories / DC Switches / A2-23C Series Push Switch

A2-23C Series Push Switch

1.Various choices, complete series, full range of styles, and multiple applications
2.Comply with RoHs compliant

Add to compare
Add to quote
Rating50A Max. 12V DC
25A Max. 24V DC
Contact Resistance50m ohm Max
Insulation ResistanceDC 500V 100M ohm Min
Dielectric StrengthAC 1500V 1minute
Operating Temperature-25°C~85°C
Switch Function3P SPST OFF-(ON)
